EN353

Grade Introduction:
We are EN353 Alloy Steel Round Bar manufacturers and we are manufacturing from prime quality billets and blooms. The range of EN353 Round Bars which we manufacture for our customers are of high quality and these round bars are used for making machinery and Auto components. These products have been made keeping in mind the quality parameters that have been set by the industry in the market.

EN353 Round Bars are always supplied with the test certificates and can be supplied in bulk quantity as well as retail quantity as per customer’s requirements. EN353 alloy Steel round bars are supplied by us to various industries. EN353 Alloy steel is a very high strength steel alloy that is hardened and tempered before supplying and has nickel, chromium, molybdenum making its high tensile steel strength, with good ductility and wear resistance. With relatively good impact properties at low temperatures, EN353 is also suitable for a variety of elevated temperature applications. EN353 round bars have good internal strength and high external strength, which makes them highly wear-resistant. EN353 steel round bars offer a good combination of ductility, strength, and wear resistance. EN353 is a very high-strength alloy engineering steel.

Grade Application

Acceptable for many automobile applications such as heavy-duty gear, shaft, pinion, camshafts, gudgeon pins.

Equivalent Grades

  • BRITISH BS 970:1991 815M17
  • BRITISH BS 970:1955 EN353
  • GERMAN DIN 20NiCrMo5
  • FRENCH AFNOR 20NCD5
  • SWEDISH SS 2523
  • EUROPEAN STEEL NAME 17NiCrMoS6-4
  • EUROPEAN STANDARD EN10277-4

Our Supply Range

We supply to automotive ancillaries and OEM customers. The products we manufacture are used as input for manufacturing of automotive and general engineering components. These components are further assembled into systems fitted in automobiles and other engineering applications.

Product Type Size Range
Forged Round Bars 140mm Dia to 850mm
Rolled Round Bars 16mm Dia and above
Forged Flat Bars Thickness: 32mm to 510mm, Width: 65mm to 1050mm
Rolled Flat Bars Thickness: 6mm to 110mm, Width: 25mm to 510mm

Chemical Composition

The following table shows the chemical composition of EN353 steel:

Element
C
Si
Mn
S
P
Ch
Mo
Ni
Content (%)
0.10-0.20
0.10-0.35
0.50-1.00
0.040 Max
0.040 Max
0.75-1.25
0.08-0.15
1.00-1.50

Heat Treatment

The hardening treatment for most steels consists of heating the steel to a set temperature and then cooling it rapidly by plunging it into oil, water. EN8 and EN353 steel is an easily available and cheap material that is acceptable for heavy-duty applications.

Hardness

HB – 270

Hardening

Hardening °C 780-820.

Thermal Properties

Thermal Conductivity at °C
20
350
700
W/(m*K)
11.3
13.3
14.5

Forging Properties

EN353 steel round bars offer a good combination of ductility, strength, and wear resistance. EN353 is a very high-strength alloy engineering steel.

Tempering

EN353 is re-heated to 780C – 820°C, holding until the temperature is uniform throughout the section, and then quenched in oil, Tempering must be done immediately while the component EN353 is still handed warm. Heat to 150C – 200°c, soak it for 1 – 2 hours / 25mm of a section, and then cooled in still air. Hardness after Tempering: 62-64 HRC.

Stress Relieving

150-200, cooled in the furnace.
1st pre-heating °C: Up to approx. 400 in an air-circulating furnace
2nd and 3rd: 780 and 805°C.

Welding

EN19 steel can be welded using all conventional techniques. However, the mechanical properties of this steel will be affected if it is welded in the heat-treated condition, and post weld heat treatment should be performed.

Machinability

75

Welding

Pre/post heat precaution required.

Mechanical Properties

Mechanical Properties
Hardening
840-870
Quenching
oil
Tempering
150-200
Brinell Rockwell Hardness
150-200

Other Details of Properties

Annealed
R
S
T
U
V
W
Y
Ruling Section (mm)
150
150
100
65
65
30
30
25
Tensile Strength (MPa)
680/720
690/850
770/930
850/ 1000
930/ 1080
1000/1160
1080/1240
1280
Yield Stress (MPa)
440/480
480
570
665
740
835
895
1050
Elongation (% Min)
22
15
15
13
12
12
10
10
ISO V Impact (Joule)
30
30
30
30
25
25
22
7
Hardness (Brinell)
190/210
201/255
223/277
248/ 302
269/ 321
293/ 341
311/ 375
363/415
Proof Stress (0.2%) if required (MPa, Min)
495
550
630
710
770
850
985

Physical Properties

Thermal Conductivity at °C
20
350
700
W/(m*K)
11.3
13.3
14.5

Normalizing

860 – 890°C in air.

Annealing

630-670°C

Density

DENSITY (G/CM 3)
8.08
DENSITY (LB/IN 3)
0.292
